HIITIO power modules are designed for efficient power conversion and control, integrating IGBT, MOSFET, and SiC technologies. They offer high power density and low loss, widely used in industrial, renewable energy, electric transportation, and home appliances.
Image | Part Number | Type | Package | Circuit Diagram | Blocking Voltage (V) | Current (A) | RDs(on) (mΩ) | Tjmax (℃) | Specifications |
|---|---|---|---|---|---|---|---|---|---|
 | SiC SBD | TO-220-2 | 1200 | 2 | ⋅ | 159 | |||
| SiC SBD | TO-220-2 | 650 | 4 | ⋅ | 153 | |||
 | SiC SBD | DFN8*8 | 650 | 6 | ⋅ | 159 | |||
 | SiC SBD | SOT-227 | 1200 | 120 | ⋅ | 108 | |||
 | SiC SBD | TO-247-3 | 1200 | 16 | ⋅ | 155 | |||
| SiC SBD | TO-247-3 | 1200 | 20 | ⋅ | 152 | |||
 | SiC SBD | TO-247-2 | 1200 | 20 | ⋅ | 150 | |||
| SiC SBD | TO-247-3 | 1200 | 40 | ⋅ | 151 | |||
| SiC SBD | TO-247-2 | 1200 | 40 | ⋅ | 155 | |||
| SiC SBD | TO-247-2 | 1200 | 60 | ⋅ | 144 | |||
 | IGBT | H1 | 3300 | 1000 | ⋅ | ||||
 | IGBT | 34mm | Half Bridge | 1200 | 100 | ⋅ | |||
| IGBT | 34mm | Half Bridge | 1700 | 100 | ⋅ | |||
 | IGBT | Easy 2B | FL: 3-level | 650 | 100 | ⋅ | |||
 | IGBT | Easy 2B | FL: 3-level | 650 | 100 | ⋅ | 150 | ||
 | IGBT | Econo PIM 3H | PIM | 1200 | 100 | ⋅ | |||
 | IGBT | Econo PIM 2H | FT: Three phase | 1200 | 100 | ⋅ | 150 | ||
| IGBT | Econo PIM 2H | FT: Three phase | 1200 | 100 | ⋅ | 150 | ||
 | IGBT | E6 | Chopper | 1700 | 1200 | ⋅ | |||
 | IGBT | H | 3300 | 1500 | ⋅ |
Contact Us Today to Discover How Our Innovative Products Can Power Your Future Projects！
With over 20 years of experience and more than 500 satisfied customers across 50+ countries, HIITIO is your trusted partner for high-voltage DC solutions in electric vehicles, solar energy systems, energy storage applications, and more.
Zhejiang HIITIO New Energy Co., Ltd brings over 20 years of power electronics expertise and a team of 70+ R&D engineers to deliver innovative energy conversion solutions worldwide.
Specializing in IGTB and MOSFET modules, power conversion systems, and advanced packaging technologies, our products power applications like electric vehicles, renewable energy systems, and industrial motor drives.
Connect with us today to transform your energy future!
Understanding the advantages of different semiconductor technologies for your application.
| Parameter | Si IGBT | SiC MOSFET | SiC/Si Hybrid | Press Pack IGBT |
|---|---|---|---|---|
| Switching Frequency | Low-Medium 1-20 kHz |
Very High 50-200 kHz |
High 20-100 kHz |
Low 0.1-5 kHz |
| System Efficiency | 95-97% | 98-99% | 97-98% | 96-98% |
| Power Density | Medium 2-5 kW/L |
Very High 10-20 kW/L |
High 5-15 kW/L |
Very High 8-25 kW/L |
| Initial Cost | Low Baseline |
High 3-5x |
Medium 1.5-2x |
Medium-High 2-3x |
| Max Junction Temp | 150°C | 200°C+ | 175°C | 125-150°C |
| Voltage Rating | Up to 6500V | Up to 1700V | Up to 1700V | Up to 6500V |
| Typical Applications | Motor Drives Solar Inverters |
EV Chargers Solar Inverters |
Industrial Drives Energy Storage |
HVDC Systems Wind Power |
| Market Maturity | Very Mature | Developing | Emerging | Mature |
Find the perfect power module for your application in 4 simple steps.
High switching frequency capability with excellent thermal performance.
Ultra-high voltage capability with superior power handling
Maximum efficiency and reliability for solar and wind applications.
Identify the application (industrial drives, PV inverters, EVs, energy storage, or grid transmission) and define requirements for performance, lifetime, and environmental conditions.
Select the appropriate voltage range (600V–6500V) and current capacity. High-voltage systems suit High Voltage IGBTs or Press Pack IGBTs; mid/low-voltage efficiency applications favor SiC Modules or SiC Discretes.
Assess switching frequency and efficiency needs. High-frequency cases (fast chargers, PV inverters) require SiC Modules, while traditional drives can use IGBT Modules.
Evaluate packaging and cooling solutions. Press Pack IGBTs excel in high thermal cycling, SiC Discretes suit compact systems, and Hybrid Modules balance heat dissipation and size.
01
02
03
04
05
06
07
08
09
HIITIO’s Semiconductor Power Modules provide efficient, high-voltage power conversion for industrial, automotive, and renewable applications.
Next-generation IGBT and SiC modules reduce switching losses and cooling needs, improving overall system efficiency.
Industrial-grade testing and advanced packaging (such as silver sintering and double-sided cooling) ensure stable operation under high loads and temperatures.
Compliant with IEC standards, backed by ISO and IATF certifications, ensuring reliability in automotive and energy sectors.
HIITIO possesses a 3,100 m² production base, including a 1,500 m² dedicated power module production line. Its 10,000-class cleanrooms support an annual capacity plan of 300,000 units, meeting high-volume delivery demands in industrial and new energy sectors
Our R&D team comprises 50% master’s/Ph.D. holders, with core members averaging over 10 years of power module development experience. We have successfully built a full product matrix covering 650-6500+ voltage ranges and 10-5000A current ratings, including mainstream topologies like PIM/6-pack/half-bridge.
Implemented 23 quality control checkpoints such as 100% X-ray void inspection and dynamic/static electrical performance testing. Products comply with IEC-60747/60749/60068 standards, and SiC modules withstand high-temperature operation up to 200°C.
IGBT suits high current, SiC enables high efficiency, and hybrids combine both for cost-performance balance.
They integrate optimized chips and packaging to reduce losses, improve thermal performance, and boost density.
Modules support air, liquid, and double-sided cooling, ensuring stable performance under high loads.
With proper cooling, modules last 15–20 years; automotive use depends on load and temperature cycles.
HIITIO offers comprehensive technical support, testing assistance, and long-term partnership services, helping major customers achieve reliable, cost-efficient, and scalable solutions.
HIITIO® was established in 2018 as a result of Hecheng Electric introducing a mature R&D team. HIITIO specializes in producing high-voltage DC electrical devices for EV, solar energy systems, and energy storage applications.
