1500Vdc 250Ka 400-2000A Fast-Acting Fuse S-105E Series
Ratings & Features Applications
- Volts: 1500Vdc
- Amps: 400-2000A
- Interrupting Capacity: 1500Vdc 250kA (L/R ≤ 5ms); Min BC: ≥ 2 In
- Class Type: aR
- Design For DC Applications
- Low arc voltage and low energy let-through(I2t)
- DC Drives
- Battery pack protection
- Excellent Dc Performance
- Superior cycling capability
,
,
,
Description
Standards / Approvals
- Refer To UL 248-13, IEC 60269-4
- Reach Declaration Available Upon Request
- CE
- RoHS Compliant
Work/Storage condition
- Work within the temperature -40℃ to +100℃ range.
- This product is a bolt-connected fuse for partial range protection, with strong current limiting, high breaking capacity, and other characteristics.
- It is suitable for energy storage, wind power, and other industry applications, which can be used as short-circuit protection for energy storage systems, power systems, and other devices and equipment.
Fuse Ratings
| Part No. | Fuse | Size | Average @ 250KA/1500Vdc | Power Loss (W) 1.0In | ||
| Amps | A²s Melting | A²s Clearing | ||||
| HCHVT1500-400S-105E | 400 | 4 # | 25,834 | 136,415 | 190 | |
| HCHVT1500-500S-105E | 500 | 4 # | 57,389 | 276,828 | 195 | |
| HCHVT1500-630S-105E | 630 | 4 # | 117,654 | 567,527 | 228 | |
| HCHVT1500-700S-105E | 700 | 4 # | 162,326 | 783,014 | 245 | |
| HCHVT1500-800S-105E | 800 | 4 # | 240,110 | 1,158,220 | 255 | |
| HCHVT1500-900S-105E | 900 | 4 # | 345,759 | 1,667,836 | 276 | |
| HCHVT1500-1000S-105E | 1000 | 4 # | 470,616 | 2,270,110 | 290 | |
| HCHVT1500-1100S-105E | 1100 | 4 # | 623,250 | 3,006,366 | 310 | |
| HCHVT1500-1200S-105E | 1200 | 4 # | 754,483 | 3,620,561 | 319 | |
| HCHVT1500-1250S-105E | 1250 | 4 # | 918,230 | 4,429,260 | 326 | |
| HCHVT1500-1300S-105E | 1300 | 4 # | 1,009,830 | 5,254,527 | 335 | |
| HCHVT1500-1350S-105E | 1350 | 4 # | 1,294,848 | 6,245,949 | 347 | |
| HCHVT1500-1400S-105E | 1400 | 4 # | 1,399,970 | 6,986,564 | 352 | |
| HCHVT1500-1500S-105E | 1500 | 4 # | 1,581,795 | 7,630,093 | 360 | |
| HCHVT1500-1600S-105E | 1600 | 4 # | 1,927,554 | 9,297,929 | 372 | |
| HCHVT1500-1800S-105E | 1800 | 4 # | 2,734,600 | 13,190,870 | 392 | |
| *HCHVT1500-2000S-105E | *2000 | 4 # | 3,603,985 | 18,860,380 | 410 | |
| *：If there are any requirements, please communicate with the original factory staff first. | ||||||
