| Electrical features | Standard | IEC 61009-1, GB16917.1 |
| Rated curret(In) | 6A,10A, 16A, 20A,25A,32A,40A | |
| Trip curve | B,C,D | |
| Model | Electronic | |
| RCD Type | AC,A | |
| Pole | 1P +N | |
| Rate voltage(Ue) | 240V | |
| Insulation voltage(Ui) | 500V | |
| Rated frequency | 50Hz | |
| Energy limiting class | 3 | |
| Rated residual operating current(lΔn) | 30mA,100mA,300mA | |
| Rated breaking capacity (Icn) | 6KA | |
| Rated operating short circuit breaking capacity(Ics) | 6KA | |
| Rated residual making and breaking capacity | (2000A) | |
| Rated impulse withstand voltage(Uimp) | 4KV | |
| Surge current resistance/at(8/20)us | 3KA | |
| Electrical life | 4,000 | |
| Protection degree | 2 | |
| Mechanical life | Mechanical features | 20,000 |
| Pollution degree | IP20 | |
| Ambient temperature(with daily averages35℃) | -25℃+40℃ | |
| Storage temperature | -25℃+70℃ | |
| Installation | Terminal connection type | Cable, busbar |
| Connection capacity(input) | 25m㎡ | |
| Connection capacity(output) | 16m㎡ | |
| Tightening torque(input) | 2.5Nm | |
| Tightening torque(output) | 1.2Nm | |
| 35mm DIN rai1 |
