| Model | BMF36808P | |
|---|---|---|
| Type | 38.4V808Ah | |
| Cell Type | LiFePO4 | |
| Cell | 202Ah CELL | |
| Combination Mode | 4PCS | |
| Capacity | 808Ah | |
| Nominal Volume | 31.02KWh | |
| Nominal Voltage | 38.4V | |
| Overcharge protection voltage | 43.8V | |
| Discharge Cut-off Voltage | 30V | |
| Standard charge current | 200A | |
| Standard discharge current (continuous) | 202A | |
| Maximum continuous charge current | 200A | |
| Maximum continuous discharge current | 808A | |
| IP grade | IP54 | |
| Weight | 907Kg±10% including counter weight | |
| Battery Dimensions(mm) | 976(L) x 413(W) x 787(H) | |
| Cycle Life | 4000 Times | |
| Self-discharge Rate | <4% | |
| Operating Temperature | Charge | 0℃~55℃ |
| Discharge | -20℃~60℃ | |
| Storage Temperature (SOC>60%) | 25℃ | |
| Certification | UN38.3 | |
| Warranty time | 5 years or 10,000 hours, whichever comes first | |
